The RAIS Visio 2 Corner Large Inset Wood Burning Fire is a substantial two-sided fireplace insert designed specifically for corner installations. With extra-large panes on the front and side, the Visio 2 L provides a wide view of the flames while keeping the surrounding frame deliberately discreet.
Its two-sided glass configuration makes it particularly effective where a fireplace is positioned at the end of a wall, within a projecting chimney breast or as part of a bespoke architectural corner. Rather than restricting the fire to a conventional frontal view, the Visio 2 L allows the flames to remain visible from two adjoining directions.
The appliance uses large panes with minimal visible framing, placing the emphasis on the fire rather than the structure of the insert. This creates a clean, contemporary appearance and helps the fireplace integrate naturally into the surrounding wall.
Access to the combustion chamber is provided through a vertical sliding door, which opens by pushing the pane upwards. This avoids the need for a hinged door projecting into the room and helps maintain the uncluttered look of the installation.
The handle can be specified in wood, black or stainless steel, allowing a subtle degree of customisation to complement the surrounding interior.
The supplied technical specification lists a rated output of 10.3kW, with an operating range of approximately 8–12kW. Efficiency is listed at 81%, with an A+ energy efficiency class, making the Visio 2 L a high-output option intended for larger residential spaces.
The appliance also incorporates the RAIS Advanced Glass Concept®, developed to create favourable combustion conditions around the glazing and help maintain a clear view of the flames during normal operation.
For installations where a large panoramic fire is required but a three-sided model is unnecessary, the RAIS Visio 2 L offers a strong balance of scale, architectural simplicity and two-sided visibility.
Key Features
- Large two-sided inset wood burning fire
- Designed for corner installations
- Extra-large front and side glazing
- Minimal visible framing
- Wide panoramic flame view
- Vertical sliding door
- Upward-opening glass
- Wood, black or stainless-steel handle options
- Rated output of 10.3kW
- Output range of approximately 8–12kW
- 81% efficiency
- A+ energy efficiency class
- 200mm flue outlet
- RAIS Advanced Glass Concept®
- Suitable for large living areas
- Suitable for bespoke architectural fireplace installations
- Available in left- or right-hand corner configurations
Expert Insight
The Visio 2 L is particularly useful where the fireplace needs to turn a corner rather than project into the room from three sides. Its large glazed area allows the fire to be viewed from two adjoining directions, while the 10.3kW rated output makes it suitable for larger spaces where a smaller corner insert may not provide sufficient heat.
Suitability
The RAIS Visio 2 Corner Large Inset Wood Burning Fire is particularly suited to large contemporary living rooms, corner chimney breasts, open-plan interiors and bespoke architectural fireplace projects where a substantial two-sided wood fire is required.
Installation / Technical Notes
Key supplied technical data:
- Product: RAIS Visio 2 L Wood
- Appliance type: Large two-sided corner inset wood burning fire
- Rated output: 10.3kW
- Output range: 8–12kW
- Efficiency: 81%
- Energy efficiency class: A+
- Combustion chamber dimensions: 660mm W x 256mm D x 545mm H
- Installation dimensions: 1088mm W x 504mm D x 504mm H
- Outer frame dimensions: 1086.6mm W x 504mm D x 563mm H
- Flue outlet diameter: 200mm
- Particulates: 1.0g/kg
- Additional heat accumulation stones: 42–70kg
- Manufacturer Clearances
- To ceiling: 500mm
- To floor: 315mm
- To furniture: 1250mm
The supplied technical information indicates that the Visio 2 L is available in left- and right-hand corner configurations, so the correct version must be selected before the surrounding fireplace structure is built.
The quoted 120–180m² heating reference is based on the conditions used in the supplied technical data and should not replace a property-specific heat-loss calculation.
Final recess dimensions, structural support, hearth construction, combustion air requirements, flue specification and combustible clearances should be confirmed against the current RAIS installation manual and technical drawing before installation.
