The Reeded Cast Iron Fireplace Chamber Lining Panels – 15mm provide a robust and historically appropriate solution for lining the internal chamber of a traditional fireplace. Commonly used in Georgian fireplace restorations, heritage properties and reproduction period interiors, these solid cast iron panels recreate the classic vertical fluted appearance associated with original fireplace chamber linings.
Manufactured from solid cast iron, each panel creates a durable and heat-resistant surface suitable for use within fireplace chambers serving compatible solid fuel appliances. The substantial construction makes these panels particularly well suited to restoration work where authenticity, longevity and a traditional finish are important.
The regular vertical reeded design adds depth and definition to the fireplace opening while providing the architectural character expected from a period-style installation. It works especially well in Georgian interiors, larger traditional fireplaces and inglenook settings where the full chamber is intended to be lined.
These panels are designed for use with a cast iron firegrate featuring an integral small back. This helps create the correct relationship between the grate and chamber lining while producing a more cohesive and historically accurate finished appearance. The firegrate or basket is not included and must be selected separately.
A wide range of panel sizes is available, allowing the chamber lining to be configured around standard fireplace openings as well as larger bespoke projects. Panels can be cut on site using an angle grinder, giving the installer additional flexibility when adapting the cast iron to suit the exact opening.
The nominal panel thickness is approximately 15mm, with a stated manufacturing tolerance of ±3mm. Due to the casting process, slight variations in panel weight and dimensions should be expected. A 12mm sizing tolerance should be allowed when planning the chamber and ordering the required panels.
With their substantial cast iron construction, authentic reeded detailing and broad choice of sizes, the Reeded Cast Iron Fireplace Chamber Lining Panels – 15mm are an excellent choice for traditional fireplace rebuilding and period restoration projects.
Key Features
- Solid cast iron fireplace chamber panels
- Traditional vertical reeded design
- Approximately 15mm thick
- Suitable for Georgian restorations
- Suitable for period-style fireplaces
- Designed for full chamber lining
- Compatible with suitable solid fuel installations
- Designed for use with an integral-back firegrate
- Multiple panel sizes available
- Suitable for standard fireplace chambers
- Suitable for larger inglenook openings
- Can be cut on site
- Suitable for cutting with an angle grinder
- Durable and heat-resistant construction
- Individual chamber panels only
- Firegrate or basket not included
Expert Insight
These heavier cast iron panels are best suited to projects where an authentic period finish is more important than minimising weight or thickness. Correctly paired with an integral-back cast iron firegrate, they can recreate the appearance and construction style associated with traditional Georgian fireplace chambers.
Suitability
The Reeded Cast Iron Fireplace Chamber Lining Panels – 15mm are suitable for Georgian fireplace restorations, heritage properties, period reproductions, and traditional fireplace chambers designed around a compatible cast iron firegrate with an integral back.
Installation / Technical Notes
Available panel sizes are approximate:
- 16″ x 36″ — 400mm x 915mm, approximately 41kg
- 16″ x 40″ — 400mm x 1015mm, approximately 43kg
- 18″ x 36″ — 455mm x 915mm, approximately 46kg
- 18″ x 40″ — 455mm x 1015mm, approximately 49kg
- 30″ x 36″ — 760mm x 915mm, approximately 78kg
- 30″ x 40″ — 760mm x 1015mm, approximately 87kg
- 48″ x 40″ — 1220mm x 1015mm, approximately 145kg
- 60″ x 40″ — 1525mm x 1015mm, approximately 156kg
Nominal thickness is 15mm with a tolerance of ±3mm. Allow approximately 12mm tolerance when sizing the panels and fireplace chamber.
The panels can be cut on site using a suitable angle grinder. Final sizing, support, fixing, expansion allowance and appliance clearances must be confirmed by the installer.
These are chamber lining panels only. The cast iron firegrate, basket and other fireplace components are not included.
