A tall gas fireplace that boasts a beautiful minimal stylish feel. The Bellfires Vertical Bell Small 3 is a contemporary gas fire. This appliance is for a balanced flue system. An insert fireplace with a minimalist design.

This appliance would be ideal for building in, combined with television or furniture. A sleek, high quality gas fireplace with a durable construction. The fire creates amazingly large flames and adapts to the narrow upright display giving the view of a taller flame.

This gas appliance features different burner options with polished or anti-reflective glass. Simply press the button on the remote control and the fire will light. This fire features different burner options and takes full advantage of the fuel bed.

The ceramic logs are very realistic and moulded in such a way they pronounce the flame effects. This appliance comes standard including Floating Frame or Hidden Door, Line Fire or Centre Fire, polished glass, steel panels or plain background, burner decoration and remote control.

*Only possible in combination with set high adjustable feet (4) / Not in combination with wifi module.

** Only possible in combination with floating frame.

Dimensions Manual: MT_VBS_3 (1)

Installation Manual: IM_Vertical_Bell_Small_3_EN_CF-LF_IV

Features

• Highly Efficient Gas Fire
• Large Vertical Glass Display
• 2-7 kW Heat Output
• Natural or LPG Gas
• Balanced Flue Gas Fire
• Minimal Contemporary Style
• Many Styling Options

A highly efficient gas fire that holds a ‘B’ energy class rating, excellent fuel economy and therefore low running costs without compromising on its performance. Several burner options are also available that have different levels of depth and character so that you can configure your Vertical gas fire exactly how you like it.

Personalise your Vertical Bell with the three interior linings; standard plain, steel panels or ceramic black mirror interior to really create a gas fire that is unique and special to you. The different interior linings add depth and bounch off the flames providing a very immersive fire.

Why not upgrade? Opt for anti-reflective glass to display the flames flawlessly, otherwise stick with the standard highly polished glass which still has an incredible reflective rating average of just 8%.

Take full control of your Vertical, without having to leave your sofa, use the standard provided thermostatic remote control or upgrade to a wifi module so that you can operate your appliance via a mobile phone or tablet using the Bellfires app.

Vertical Bell Range

• Small 3 Gas Fire
• Small 3 Tunnel Gas Fire
• Medium 3 Gas Fire
• Medium 3 Tunnel Gas Fire
• View all Bellfires Vertical Bell Range

Frames

Different frame choices change the look and feel of the Vertical Bell. The floating frame makes the fire look as if it is suspended and the hidden door allows you to change the thickness of the frame around the outside.

• Floating Frame – Makes the fire look almost as if it is floating (hence the name) and suspended for a minimal and clean look.
• Hidden Door – Change the thickness of the fire with the hidden door frame. Available as a standard size or (+ 7cm) (+ 10cm).

The Vertical Bell frames are all very minimal and allow for a smooth and flush finish upto the edges of the frames. The Topsham is ideal for bespoke media walls or false chimney breasts.

Interior Linings

Three interior linings The View Bell 3 fires all have the option for 3 different linings and 3 different fuel beds. Standard finishes are the Steel panels and plain background with an optional third highly decorative ceramic black mirror finish to give depth to the overall flame picture.

• Plain Background – A plain background that has high heat retention that focuses the eye towards the flames effects.
• Steel Panels – Steel panels that reflect the flames to create more depth to the fire. Overall, creating a stunning fire chamber look.
• Ceramic Black Mirror Interior – A black mirrored interior lining that beautifully mirrors the fire sutterly for more depth and contrasting flames against a black background.

Burner Decorations (Fuel Beds)

Burner decorations are essential in creating the perfect flame effect. They distrupt the flame burner and move the flames in a life-like way to create an immersive fire that works well at all settings. Three different burner decorations are available for the Vertical Bell Small gas fire.

Personalise the Vertical 3 gas fire just how you like it. Whether you like wood logs, grey stones or white marble shingles. On this gas appliance the wood logs and grey stones come togethor with white marble shingles as a seperate fuel bed decoration. View the options below:

• Wood Logs – Realistic ceramic painted logs that look almost unrecognisable from real logs. Each log is handpainted and has been specifically moulded to suit the Vertical Bell Small fires fuel bed burners. This is essential to creating the most immersive and exciting flames that works well on all settings.
• Grey Stones – Grey stones that sit around the burners for a rocky fuel bed look whereby the flames gently peak through.
• White Marble Shingles – Marble adds a stylish high quality look and feel. Small shingles that sit around the fire burners on the fuel bed so that the flames can gently peak through.

Double Burners

The Vertical Bell range features two different double burner options; the line fire burner and centre fire burner. Featuring innovative patented technology, each have individual character and create a different atmosphere. Bellfires burners are highly efficient with their power saving mode and eco ready functionality without compromising on the quality of the flames.

The Line Fire burner is a double burner system that are strategically placed in lines on after the other, this creates an immersive 4d flame with rich depth.

The Line Burner can also be adapted to a slow and low power mode which just turns on the front burners, which spans the whole width of the fuel bed. This inturn produces less heat but still allows you to have a rich looking flame that spans the whole fuel bed. Works very well on a large horizontal fire.

See Line Fire video preview below:

Click HERE to view LPG (Propane) gas Line Fire burner effect.

The second burner option is the Centre Fire burner. The flames are placed next to each other and it allows you to switch off the side of the burner for a richer and fuller centre fire. By switching off the sides is also produces less heat, if you wish. This burner is especially good for more compact and smaller fires like the Vertical Bell Small 3.

Controls

The Vertical Bell Small can be fully controlled via the sleek looking Bellfires thermostatic remote control or Bellfires App that can be accessed on a tablet or mobile phone. This gives you the ability to control the settings of your Vertical Bell Small with the tap of a button without having to leave your sofa. Set the temperature and timer abilities

Wifi Module

The wifi module allows you to operate your Bellfire gas fire via your mobile or tablet at the touch of a button, so you don’t even have to leave your sofa to operate it. The Bellfires app is very intuiative and allows you to control the heating and timer for your Vertical Bell along with other settings and quirky features.

Dimensions

• Appliance Unit (with standard hidden door): L: 59.7 cm W: 43.2 H: 88.3 cm.
• Glass Display (with standard hidden door): L: 53.4 cm H: 48 cm.
• Appliance Unit (floating frame): L: 59.7 cm W: 44.2 H: 88.3 cm.
• Glass Display (floating frame): L: 53.4 cm H: 55 cm.
• Optional +7 cm and +10 cm around hidden door thicknesses.

Vertical Bell Small 3 Installation

The Vertical Small gas fireplace from Bellfires requires a qualified Gas Safe engineer to install and service the appliance to ensure that the gas fire is safe, complies with distance to combustible and manufacturers requirements. Official Bellfires flue systems are also recommended, this will ensure your Vertical Bell Small will qualify for your full Bellfires 10 year warranty. Purchasing through an official Bellfires dealer such as Bonfire, will ensure you get the best after care sales & support and yearly servicing, along with a safe and flawless installation.

• Four ‘Set high adjustable feet’ from Bellfires can be used for installation so that the appliance can be set at the exact height. (+£60).
• Handle connections for lifting can be used for this appliance, specifically from Bellfires.
• Convert your Vertical gas appliance to a conventional flue appliance with our conversion kit. (See flue type dropdown)
• A convection case is an extra casing that goes around the fire to improve air flow.  (+£126).

If you would like help or advice with the configuration and installation of your Bellfires appliance, please get in contact with our team.
